NaviaTec Fiber Optics
Prikazujemo 1–15 od 102 rezultata
-
Optičke mreže pasivne
NFO Anchor clamp for round cables, diameter 10-16 mm, 17,5kN, bail 340 mm
NFO Anchor clamp for round cables, diameter 10-16 mm, 17,5kN, bail 340 mm – Cable diameter range: 10-16 mm Dimensions of body: 42x82x200 mm Length of bail: 340 mm Minimum breaking force: 17,5 kN Weight: 0.3 kg Made of high quality thermoplastic material Wedge installation Solid construction UV resistant Weather resistance Tool-free assembly Rapid, simple installation Removable stainless steel bail Blocking plastic wedges
Šifra: NFO-TOOL-80006 -
Optičke mreže pasivne
NFO Anchor clamp for round cables, diameter 11-15 mm, 15kN, bail 600 mm
NFO Anchor clamp for round cables, diameter 11-15 mm, 15kN, bail 600 mm – Cable diameter range: 11-15 mm Dimensions of body: 112x63x30 mm Length of bail: 600 mm Minimum breaking force: 15 kN Weight: 0.5 kg Made of high quality aluminum Wedge installation Solid construction UV resistant Weather resistance Tool-free assembly Rapid, simple installation Removable stainless steel bail Blocking plastic wedges
Šifra: NFO-TOOL-80004 -
Optičke mreže pasivne
NFO Anchor clamp for round cables, diameter 15-20 mm, 16kN, bail 340 mm
NFO Anchor clamp for round cables, diameter 15-20 mm, 16 kN, bail 340 mm – Cable diameter range: 15-20 mm Dimensions of body: 42x82x200 mm Length of bail: 340 mm Minimum breaking force: 17,5 kN Weight: 0.3 kg Made of high quality thermoplastic material Wedge installation Solid construction UV resistant Weather resistance Tool-free assembly Rapid, simple installation Removable stainless steel bail Blocking plastic wedges
Šifra: NFO-TOOL-80007 -
Optičke mreže pasivne
NFO Anchor clamp for round cables, diameter 8-12 mm, 15kN, bail 350 mm
NFO Anchor clamp for round cables, diameter 8-12 mm, 15kN, bail 350 mm – Cable diameter range: 8-12 mm Dimensions of body: 112x63x30 mm Length of bail: 350 mm Minimum breaking force: 15 kN Weight: 0.5 kg Made of high quality aluminum Wedge installation Solid construction UV resistant Weather resistance Tool-free assembly Rapid, simple installation Removable stainless steel bail Blocking plastic wedges
Šifra: NFO-TOOL-80003 -
Optičke mreže pasivne
NFO Cable rack 600 mm
NFO Cable rack 600 mm – fiber optic cable rack is designed for collecting and organizing the supply of linear cable with different diameters. Racks guarantee functionality and the correct bending radius of the cable. They are used in cable rooms or telecommunications wells. They are made of high quality aluminum alloys 30x5mm high quality aluminum flat bars, mechanical resistance and weather conditions, UV resistant 600x600mm Middle threaded hole for mounting the tray: M6 Mounting holes o10 Weight: 1,1 kg
Šifra: NFO-TOOL-80063 -
Optičke mreže pasivne
NFO Clamp for round cables, diameter 8-12 mm, 16 kN
NFO Clamp for round cables, diameter 8-12 mm, 16 kN – designed for hanging round self-supporting cables high quality thermoplastic and mechanical resistance as well as weather conditions, resistant to UV Minimum breaking load: 17.5 kN Lenth length with cable: 700 mm Length of the body: 200 mm
Šifra: NFO-TOOL-80044 -
12 Fiber#
NFO Fiber optic cable Fibertechnic ADSS Z-XOTKtsdDb 12F 1Tx12F, G.657A1, 2,0kN, Span 70m, 1m
12 Fiber#NFO Fiber optic cable Fibertechnic ADSS Z-XOTKtsdDb 12F 1Tx12F, G.657A1, 2,0kN, Span 70m, 1m
NFO Fiber optic cable Fibertechnic ADSS Z-XOTKtsdDb 12F 1Tx12F, G.657A1, 2,0kN, Span 70m, 1m, cijena po 1m – PRODAJA ISKLJUČIVO U KOLUTU OD 200m 12 fiber 1x Active tube 12x fiber in 1 tube Total diameter 8,2mm Corning SMF-28 Ultra fibre ITU-T G.652D G.657A1 Multi-tube, self-supporting construction with high pulling resistance, core reinforcing element (FRP rod), gel and water blocking design (WB), moisture absorbing fibres (WSY) anti-moisture tape, fully dielectric, glass fibre reinforced, PE sheath 1.2 mm – UV resistant Weight kg km 55kg km
Šifra: NFO-CBL-S90017 -
4 Fiber#
NFO Fiber optic cable Optix FTTH AirFlow S-QOTKSdD, DROP, 4F, 9 125, ITU-T G.657A2, 0,8kN…
NFO Fiber optic cable Optix FTTH AirFlow S-QOTKSdD, DROP, 4F, 9 125, ITU-T G.657A2, 0,8kN, Span 80m, 1m – PRODAJA ISKLJUČIVO NA KOLUTU OD 1 km Packaged on rotating reels Universal, self-supporting fiber optic cable adjusted to use outdoor and indoor Reinforced with aramid fibers Resistant to radiation UV and totally dielectric Designed for aerial installation with bays of 80-100m and installations in primal and secondary teletechnical canalization Light one-tube design External diameter 3,0mm PU coating, UV resistance Temperature range -20 to 60 C Bending radius – 7.5 mm
Šifra: NFO-CBL-S90036 -
Optičke mreže pasivne
NFO Fiber optic cable ZTT Z-ADSS.UT-02J, 2F, ADSS, G.652D, 1.2kN, Span 80m, 1m
NFO Fiber optic cable ZTT Z-ADSS.UT-02J, 2F, ADSS, G.652D, 1.2kN, Span 80m, cijena po 1m PRODAJA ISKLJUČIVO U KOLUTU OD 1000m – 4 fiber 1x tube 4x fiber in 1 tube Total diameter 5,2 mm Universal one tube cable, aerial SPAN 80m or tele-technical canalisation. It is enhanced with aramid fibers and two FPR (Fiber Reinforced Polymer) rods Light construction ( 23kg km), large flexibility and durability. The fibers are located in a central tube filled with a hydrophobic gel that protects them from moisture and vibrations. HDPE coat, UV resistant shell, temperature range between -43 and 70 C Maximum tensile force: 1.2 kN Pressure resistance: 1 kN Weight: 23 kg km Za ostale dužine kabla javite se vašem prodajnom referentu
Šifra: NFO-CBL-S90003 -
Optičke mreže pasivne
NFO Fiber optic cable ZTT Z-ADSS.UT-08J, 8F, ADSS, G.652D, 1.2kN, Span 80m, 1m
NFO Fiber optic cable ZTT Z-ADSS.UT-08J, 8F, ADSS, G.652D, 1.2kN, Span 80m, cijena po 1m PRODAJA ISKLJUČIVO U KOLUTU OD 500m – 8 fiber 1x tube 8x fiber in 1 tube Total diameter 5,2 mm Universal one tube cable, aerial SPAN 80m or tele-technical canalisation. It is enhanced with aramid fibers and two FPR (Fiber Reinforced Polymer) rods Light construction ( 23kg km), large flexibility and durability. The fibers are located in a central tube filled with a hydrophobic gel that protects them from moisture and vibrations. HDPE coat, UV resistant shell, temperature range between -43 and 70 C Maximum tensile force: 1.2 kN Pressure resistance: 1 kN Weight: 23 kg km Za ostale dužine kabla javite se vašem prodajnom referentu
Šifra: NFO-CBL-S90016
