WD 8TB Black SN850X M.2 2280 PCI-e 4.0 NVMe 1.4 SSD drive

The WD BLACK SN850X (WDS800T2X0E) offers 8 TB of capacity in the M.2 2280 format and uses a PCIe 4.0×4 interface with the NVMe protocol, enabling top-notch data transfer speeds and near-instantaneous response times. The SSD is equipped with 3D TLC NAND technology and supports hardware encryption (TCG Opal Encryption) for added security. With compatibility with Microsoft DirectStorage technology and features such as STA Adaptive Thermal Management and Overhead Balancing, it delivers optimized performance for demanding workloads and games. It is compatible with motherboards with an M.2 2280 slot and supports PCIe Gen4 platforms. Its capacity and performance make it suitable for users who demand maximum performance and reliability.

Specifications:
Model: WDS800T2X0E
Capacity: 8 TB
Form factor: M.2 2280
Interface: PCIe 4.0 ×4 NVMe
Sequential read: up to ≈ 7,300 MB/s
Sequential write: up to ≈ 6,600 MB/s
Random read (4 KB): up to ≈ 1,200,000 IOPS
Random write (4 KB): up to ≈ 1,200,000 IOPS
Writing technology: 3D TLC NAND
Endurance (TBW): 4800 units
Hardware encryption: yes (TCG Opal V2.01)
MTBF: approximately 1,750,000 hours
Compatibility: Windows 10+, PlayStation 5 (Heatsink model only)
Dimensions (L × W × H): approximately 80 × 22 × 2.38 mm
Weight: approximately 8.6 g
Certifications: BSMI, CAN ICES-3(B)/NMB-3(B), CE, FCC, KCC, Morocco, RCM, TUV, UL, VCCI

Package contents: SSD WDS800T2X0E, documentation
