TP-Link bežična pristupna točka vanjska (AP) 300Mbps (2.4GHz), 802.11b/g/n, podrška za Pasive PoE, 2×LAN, WISP Client Router, QCA, 2×12dBi usmjeriva antena

Šifra: CPE220

Jamstvo (mj): 36 mjeseci

Dostupnost:

Dostupno kod dobavljača. Isporuka 3-5 dana!


409,00kn

Dostupno kod dobavljača. Isporuka 3-5 dana!

– Built-in 12dBi 2×2 dual-polarized directional MIMO antenna – Adjustable transmission power from 0 to 30dBm/1000mw – System-level optimization for more than 5km long range wireless transmission – TP-LINK Pharos MAXtream TDMA(Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency, ideal for PTMP applications – Centralized Management System – Pharos Control – AP / Client / Repeater / AP Router / AP Client Router (WISP) operation modes – Outdoor stabilized enclosure with IPX5 waterproof certification – Dual Ethernet ports and grounding terminal integrated – 6000V Lightning Protection, 15KV ESD Protection – Passive PoE Adapter supports up to 60 meters (200 feet) power over Ethernet deployment and allows for device reset remotely – Provides WEP, WPA/WPA2, WPA-PSK/WPA2-PSK data security – Selectable bandwidth of 5/10/20/40MHz – Provides Throughput Monitor, Spectrum Analyzer, Speed Test and Ping tools – Easy antenna alignment with wireless signal quality indicators via Web interface HARDWARE FEATURES – Processor: Qualcomm Atheros 560MHz CPU, MIPS 74Kc – Memory: 64MB DDR2 RAM, 8MB Flash – Interface: * 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) * 1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough) * 1 Grounding Terminal * 1 Reset Button – Power Supply: Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) – Voltage range: 16-27VDC – Dimensions (W×D×H): 276×79×60 mm – Power Consumption: 10.8 Watts Max ** Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable – Antenna Type: * Built-in 12dBi 2× 2 Dual-polarized Directional Antenna * Beam Width: 60° (H-Plane) / 30° (E-Plane) ** Note: For more details, please refer to datasheet – Protection: * 15KV ESD Protection * 6000V Lightning Protection – Enclosure: * Outdoor ASA stabilized plastic material * IPX5 waterproof Certification WIRELESS FEATURES – Wireless Standards: IEEE 802.11b/g/n (with Pharos MAXtream disabled) – Proprietary Protocol: TDMA Mode (with Pharos MAXtream enabled) – Wireless Speeds: * Up to 300Mbps (40MHz,Dynamic) * Up to 144.4Mbps (20MHz,Dynamic) * Up to 72.2Mbps (10MHz,Dynamic) * Up to 36.1Mbps (5MHz,Dynamic) – Frequency: 2.4 – 2.483GHz ** Note: Available operating frequency may vary depending on the limitations of the countries or regions in which the device is used – Transmission Power: 30dBm/1000mw (Adjustable power by 1dBm) ** Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions in which the device is used SOFTWARE FEATURES – Wireless Configurations: * Pharos MAXtream TDMA Technology * 802.11b/g/n Modes * Selectable Channel Width: 5/10/20/40MHz * Automatic Channel Selection * Transmission Power Control * Dynamic Frequency Selection (DFS) * WDS Enable/Disable * Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption, 64/128/152-bit WEP Encryption * SSID Broadcast Enable/Disable * Multi-SSID with VLAN Tagging (AP mode only) * Distance/ACK Timeout Setting * Wireless MAC Address Filter * Wireless Advanced: * > Beacon Interval/RTS Threshold/Fragmentation * >Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia – Management: * Discovery and Remote Management via Pharos Control application * HTTP/HTTPS Web-based management * System Log * SNMP Agent(v2c) * Ping Watch Dog * Dynamic DDNS * SSH Server – System Tools: * Wireless Signal Quality Indicators: * Signal Strength/Noise/Transmit CCQ/CPU/Memory * Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP * Spectrum Analyzer * Speed Test * Ping * Traceroute – System-level Optimizations: Optimized IGMP Snooping/Proxy for multicast applications Hardware watch dog POE ADAPTER FEATURES – Interfaces: * 1 AC Jack with Earth Ground * 1 10/100Mbps Shielded Ethernet Port (Power + Data) * 1 10/100Mbps Shielded Ethernet Port (Data) – Efficiency: >80% – Button: Remote Reset Button – Certifications: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark – Power Status LEDs: * 0-0.8A: Green * 0.8A-1.0A: Red – Output: * 24VDC, 1.0A Max * +4, 5pins; -7, 8pins. (Support up to 60m Power over Ethernet) – Input Voltage: 100VA-240VAC @ 50Hz-60Hz – Dimensions(W×D×H): 110×57×33.5 mm – Input Current: 0.8A Max @ 100VAC – Input: 100-240VAC, 50/60Hz – Output Voltage: 24VDC(+4,5pins; -7,8pins) OTHERS – Certification: CE, FCC, RoHS, IPX5 – Package Contents: Outdoor Wireless CPE, 24V 1A Passive PoE Adapter, Pole Mounting Straps, AC Power Cord, Installation Guide – System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux ** Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended – Environment: * Operating Temperature: -30C – 70C (-22F – 158F) * Storage Temperature: -40C – 70C (-40F – 158F) * Operating Humidity: 10%-90% non-condensing * Storage Humidity: 5%-95% non-condensing

SKU: CPE220 Kategorija: Brand:
