Karakteristike |
• IP video ulaz: 32-ch • podržava kamere do 32MP • VCA događaji, Alarm ulaz/izlaz • 2 SATA sučelja do 16 TB za svaki pojedini HDD |
|
Bandwith snimanja |
320Mbps |
|
Dvosmjerni audio ulaz |
1-ch RCA (2.0Vp-p, 1kOhm) |
|
Video kompresija |
H.265+/H.265/H.264+/H.264 |
|
Rezolucija snimanja i playbacka |
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF |
|
VGA/HDMI izlaz |
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × |
|
1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × |
|
|
720/60Hz, 1024 × 768/60Hz |
|
|
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × |
|
|
1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × |
|
|
720/60Hz, 1024 × 768/60Hz VGA: 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
|
|
Audio izlaz |
1-ch RCA linearni 1kOhm |
|
Sinkronizirani playback |
2-ch@32 MP (30 fps) + 2-ch@8 MP (30 fps)/10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps) |
|
Sučelje za komunikaciju |
2 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet |
|
USB sučelje |
1 x USB 2.0, 1 x USB3.0 |
|
Napajanje |
12VDC |
|
Potrošnja struje |
≤15W (bez HDD ili DVD-R/W) |
|
Radna temperatura |
-10°C ~ 55°C |
|
Vlažnost |
10% ~ 90% |
|
Dimenzije |
385mm(Š)x315mm(D)x52mm(V) |
|
Masa |
≤3Kg (bez HDD ili DVD-R/W) |
|
Alarmni ulaz/izlaz |
• 4/1 |
