PLANET Gigabit preklopnik (Switch) 5-port 10/100/1000Mbps


155,00kn

Key Features
– Eight 10/100/1000Mbps Gigabit Ethernet ports
– Complies with IEEE 802.3, 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T
– Supports auto MDI/MDI-X function
– Hardware-based 10/100Mbps, half / full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation
– Features Store-and-Forward mode with wire-speed filtering and forwarding rates
– IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
– Integrated address look-up engine, supporting 8K absolute MAC addresses
– 9K Jumbo packet size
– Power saving ability for Green networking
– Automatic address learning and address aging
– Supports CSMA/CD protocol Made from plastic, desktop size and wall-mount design
– LED indicators for system power, per port Link / Act
– 5V DC, 1A external power adapter
– FCC, CE Class B compliant

SPECIFICATION
HARDWARE SPECIFICATION
– Hardware Version: 7
– 10/100/1000Base-T Ports: 5 auto MDI/MDIX ports
– LED Display: One for Power, One for Link / Act per port
– Enclosure: Plastic
– Dimensions (W×D×H): 168×100×29mm
– Weight (g): 138g
– Power Requirements (External power adapter): 5V DC, 1A
– Power Consumption (100M full operation): 3.3 watts / 13 BTU

SWITCH SPECIFICATIONS
– Switch Processing Scheme: Store-and-Forward
– Address Table: 2K
– Flow Control:
* Back pressure half duplex
* IEEE 802.3x pause frame full duplex
– Switch Fabric: 10Gbps
– Throughput (packet per second): 7.44Mpps
– Jumbo packet size: 9K

STANDARD CONFORMANCE
– Regulation Compliance: FCC Part 15 Class B, CE
– Standards Compliance:
* IEEE 802.3 (Ethernet)
* IEEE 802.3u (Fast Ethernet)
* IEEE 802.3ab(Gigabit Ethernet)
* IEEE 802.3x (Full-duplex flow control)
* IEEE 802.3az Energy Efficient Ethernet (EEE)

SKU: GSD-504 Kategorija: Brand:
